Battery and Charging Specialists

We specialize in battery system engineering and small run manufacturing delivering complete power solutions for high demand applications.

Our solutions are at the core of sophisticated aerospace, defense, health care and telecommunications technologies. With a full suite of prototyping and production equipment we can quickly respond to your needs.

We are an Authorized Design House for Microchip Technologies. Using low power embedded solutions we can create customized power management systems to meet your needs.

Custom Charger for Telecom Batteries

• High powered 100 bay charging system with air conditioning and safety interlocks.

• 50.4V Li-ion charger at 90W power per bay.

• Smoke and over temperature lockouts.

• 208 to 240VAC powered.

• CAN and I2C interfaces for data collection.

Custom Chargers for Medical Batteries

• racks of 5-Bay "Warehouse charger" for lease-return batteries

• System charges-discharges batteries, measures actual capacity and pass/fails batteries,

• connects to back-end database and allows operator to pass/fail based on cosmetic or physical damage to packs,

• System logs operator via fingerprint scanner to meet FDA requirements for traceability,

• Barcode logs battery serial numbers,

• Fanless, all convection and conduction cooled.

--------

• 20 bay rack mount charger for small Li-ion medical batteries. All convection cooled.

• Charger performs a discharge resistance test of the battery and reports pass/fail of charge and test through RS485 interface. Up to six 20 bay chargers can be chained together on a single RS485 interface.

• PC control mode allows PC based software to control each charger bay to perform customized tests.

Battery Cycler for Enterprise Server Manufacturer

• Battery cycler that supports charge and discharge to a target capacity.
• Features removable contact plates.

• Entire product built in-house including PCB population and assembly, laser cutting of top housing and CNC machining of main housing.

Portable Chargers for Wearable Sensors

• 24 bay wearable sensor charger with its own 86Wh internal battery for charging away from wall power.

• Spring loaded 3D printed sensor holders allow contact to be made while a bi-colour LED indicates charging status for each bay.

---------

• Two bay battery charger for a wearable sensor. 3D printed insert in off the shelf case. Everything is included, wall adapter, cord, and storage for adhesive pads.

• Internal 2800mAh pre-certified battery allows the case to charge the sensors when away from mains power.

• Bi-color indication of charging for the sensors with a 5 LED fuel gauge to show status of internal battery.

Serial Interface for Reprogramming Chargers

• Custom USB to I2C serial interface with galvanic isolation for reprogramming an existing charger system for new battery firmware.

• System identifies charger and applies update to each bay of the charger.

• Using a custom serial interface allows a low latency fast update of the charger firmware compared to an off the shelf solution.

• PC program programmed in Python + QT for rapid development and cross platform release
